微服务系列笔记之Broker模式入门篇

导语

API模式笔记告一段了，这篇文章总结了Micro中的消息订阅模式，在之前的系列文章中讲解了RabbitMQ消息队列，使用的是原生代码进行编写，在Micro中，其实为我们封装了RabbitMQ消息队列，不仅仅是RabbitMQ还有NATs作为消息中间件，称之为broker模式，在这篇文章中我们进行一个简单的发布与订阅模式的介绍。

入门案例介绍

首先建立如下目录

编写我们的main.go,首先，定义一个待发布的主题和一个broker，使用broker需要导入包。

1import "github.com/micro/go-micro/broker"

1var (
2    // 定义一个待发布的主题
3    topic = "mu.micro.book.topic.payment.done"
4    b     broker.Broker
5)

编写一个发布消息的函数如下，在代码中broker.Message是一个结构体，我们将要发送的消息需要存入该结构体中，最后使用broker.Publish发布消息。

 1func pub() {
 2    // 该Ticker包含一个通道字段，并会每隔时间段d就向该通道发送当时的时间。
 3    // 它会调整时间间隔或者丢弃tick信息以适应反应慢的接收者。如果d<=0会panic。关闭该Ticker可以释放相关资源。
 4    tick := time.NewTicker(time.Second)
 5    i := 0
 6    for range tick.C {
 7        msg := &broker.Message{
 8            Header: map[string]string{
 9                "id": fmt.Sprintf("%d", i),
10            },
11            Body: []byte(fmt.Sprintf("%d:%s", i, time.Now().String())),
12        }
13        log.Infof(broker.String())
14        // 发布消息
15        if err := broker.Publish(topic, msg); err != nil {
16            log.Infof("[pub] Message publication failed: %v", err)
17        } else {
18            fmt.Println("[pub] Message published: ", string(msg.Body))
19        }
20        i++
21    }
22}

有发布消息的函数，肯定就有接收消息的函数如下,通过broker.Subscribe完成主题的订阅。其他的调用见名知义，不再详细介绍。

 1func sub() {
 2    // 订阅消息并接收
 3    _, err := broker.Subscribe(topic, func(p broker.Event) error {
 4        log.Info("[sub] Received Body: %s,Header: %s/n", string(p.Message().Body), p.Message().Header)
 5        return nil
 6    })
 7    if err != nil {
 8        fmt.Println(err)
 9    }
10}

编写我们的main函数,这里需要注意导入相关的包

1"github.com/micro/go-micro/config/cmd"
2"github.com/micro/go-micro/util/log"

使用Init进行初始化然后开始连接，开启两个协程进行收发消息，使用time.After()设置过期时间，当时间到时，并向当前通道发送事件，结束主线程。防止主线程提前结束。如果这一点不懂请移步 我的博客 看关于进程线程和Go协程总结这篇文章。

 1func main() {
 2    cmd.Init()
 3    if err := broker.Init(); err != nil {
 4        log.Fatalf("broker.Init() error: %v", err)
 5    }
 6    if err := broker.Connect(); err != nil {
 7        log.Fatalf("broker.Connect() error: %v", err)
 8    }
 9
10    go pub()
11    go sub()
12
13    <-time.After(time.Second * 20)
14}

看到这里是不是觉得很简单，测试一番,结果如下

 1PS F:/micolearn/day02/mico-broker/basic> go run main.go
 22019/08/12 16:28:37 http
 3[pub] Message published:  0:2019-08-12 16:28:37.388162 +0800 CST m=+1.024290401
 42019/08/12 16:28:37 [sub] Received Body: %s,Header: %s
 50:2019-08-12 16:28:37.388162 +0800 CST m=+1.024290401map[id:0]
 62019/08/12 16:28:38 http
 7[pub] Message published:  1:2019-08-12 16:28:38.3884518 +0800 CST m=+2.024580201
 82019/08/12 16:28:38 [sub] Received Body: %s,Header: %s
 91:2019-08-12 16:28:38.3884518 +0800 CST m=+2.024580201map[id:1]
102019/08/12 16:28:39 http
11[pub] Message published:  2:2019-08-12 16:28:39.3878092 +0800 CST m=+3.023937601
122019/08/12 16:28:39 [sub] Received Body: %s,Header: %s
132:2019-08-12 16:28:39.3878092 +0800 CST m=+3.023937601map[id:2]
142019/08/12 16:28:40 http
15[pub] Message published:  3:2019-08-12 16:28:40.3881043 +0800 CST m=+4.024232701
162019/08/12 16:28:40 [sub] Received Body: %s,Header: %s
173:2019-08-12 16:28:40.3881043 +0800 CST m=+4.024232701map[id:3]
182019/08/12 16:28:41 http
19[pub] Message published:  4:2019-08-12 16:28:41.3884312 +0800 CST m=+5.024559601
202019/08/12 16:28:41 [sub] Received Body: %s,Header: %s
214:2019-08-12 16:28:41.3884312 +0800 CST m=+5.024559601map[id:4]
222019/08/12 16:28:42 http
23[pub] Message published:  5:2019-08-12 16:28:42.3887561 +0800 CST m=+6.024884501
242019/08/12 16:28:42 [sub] Received Body: %s,Header: %s
255:2019-08-12 16:28:42.3887561 +0800 CST m=+6.024884501map[id:5]
262019/08/12 16:28:43 http
27[pub] Message published:  6:2019-08-12 16:28:43.3870869 +0800 CST m=+7.023215301
282019/08/12 16:28:43 [sub] Received Body: %s,Header: %s
296:2019-08-12 16:28:43.3870869 +0800 CST m=+7.023215301map[id:6]
302019/08/12 16:28:44 http
31[pub] Message published:  7:2019-08-12 16:28:44.3885307 +0800 CST m=+8.024659101
322019/08/12 16:28:44 [sub] Received Body: %s,Header: %s
337:2019-08-12 16:28:44.3885307 +0800 CST m=+8.024659101map[id:7]
342019/08/12 16:28:45 http
35[pub] Message published:  8:2019-08-12 16:28:45.3887328 +0800 CST m=+9.024861201
362019/08/12 16:28:45 [sub] Received Body: %s,Header: %s
378:2019-08-12 16:28:45.3887328 +0800 CST m=+9.024861201map[id:8]
382019/08/12 16:28:46 http
39[pub] Message published:  9:2019-08-12 16:28:46.3870944 +0800 CST m=+10.023222801
402019/08/12 16:28:46 [sub] Received Body: %s,Header: %s
419:2019-08-12 16:28:46.3870944 +0800 CST m=+10.023222801map[id:9]
422019/08/12 16:28:47 http
43[pub] Message published:  10:2019-08-12 16:28:47.3873887 +0800 CST m=+11.023517101
442019/08/12 16:28:47 [sub] Received Body: %s,Header: %s
4510:2019-08-12 16:28:47.3873887 +0800 CST m=+11.023517101map[id:10]
462019/08/12 16:28:48 http
47[pub] Message published:  11:2019-08-12 16:28:48.3887128 +0800 CST m=+12.024841201
482019/08/12 16:28:48 [sub] Received Body: %s,Header: %s
4911:2019-08-12 16:28:48.3887128 +0800 CST m=+12.024841201map[id:11]
502019/08/12 16:28:49 http
51[pub] Message published:  12:2019-08-12 16:28:49.3870651 +0800 CST m=+13.023193501
522019/08/12 16:28:49 [sub] Received Body: %s,Header: %s
5312:2019-08-12 16:28:49.3870651 +0800 CST m=+13.023193501map[id:12]
542019/08/12 16:28:50 http
55[pub] Message published:  13:2019-08-12 16:28:50.3873677 +0800 CST m=+14.023496101
562019/08/12 16:28:50 [sub] Received Body: %s,Header: %s
5713:2019-08-12 16:28:50.3873677 +0800 CST m=+14.023496101map[id:13]
582019/08/12 16:28:51 http
59[pub] Message published:  14:2019-08-12 16:28:51.3886879 +0800 CST m=+15.024816301
602019/08/12 16:28:51 [sub] Received Body: %s,Header: %s
6114:2019-08-12 16:28:51.3886879 +0800 CST m=+15.024816301map[id:14]
622019/08/12 16:28:52 http
63[pub] Message published:  15:2019-08-12 16:28:52.3870503 +0800 CST m=+16.023178701
642019/08/12 16:28:52 [sub] Received Body: %s,Header: %s
6515:2019-08-12 16:28:52.3870503 +0800 CST m=+16.023178701map[id:15]
662019/08/12 16:28:53 http
67[pub] Message published:  16:2019-08-12 16:28:53.3875243 +0800 CST m=+17.023652701
682019/08/12 16:28:53 [sub] Received Body: %s,Header: %s
6916:2019-08-12 16:28:53.3875243 +0800 CST m=+17.023652701map[id:16]
702019/08/12 16:28:54 http
71[pub] Message published:  17:2019-08-12 16:28:54.3885713 +0800 CST m=+18.024699701
722019/08/12 16:28:54 [sub] Received Body: %s,Header: %s
7317:2019-08-12 16:28:54.3885713 +0800 CST m=+18.024699701map[id:17]
742019/08/12 16:28:55 http
75[pub] Message published:  18:2019-08-12 16:28:55.3872265 +0800 CST m=+19.023354901
762019/08/12 16:28:55 [sub] Received Body: %s,Header: %s
7718:2019-08-12 16:28:55.3872265 +0800 CST m=+19.023354901map[id:18]
