对于后端老鸟来说,一定遇到过这样的场景:
为了排查线上突发的问题,非常希望能够全面的看到请求在服务链路上的完整日志输出;
But,在生产环境中,为了避免日志打印过量造成磁盘空间浪费,通常会将日志级别设定在INFO,并关闭一般情况用不到的日志输出;
在不重启服务的情况下,开启本已经关闭的业务日志输出,能不能搞的定呢?答案是当然没问题。
熟悉logback的同学此时肯定已经想到通过扫描监听logback.xml文件配置变化来实现日志级别的调整,像如下这种方式:
<configuration debug="true" scan="true" scanPeriod="1 seconds">
但通常情况下,你的业务服务是分布式部署的,后端节点有多台,如果一台台的去改,且不说运维大哥未必就会同意给你生产机器文件的修改权限,即使可以,这么做未免有些过于“老实”了;有没有一种可以集中管理日志配置,修改文件后再逐个分发给各节点的解决方案呢?沿着这个思路,自然而然就会联想到配置中心,这里,我主要介绍携程开源的apollo,同类的配置中心产品还有百度Disconf、阿里ACM和Spring Cloud Config,感兴趣的自行研究。
熟悉apollo文件管理的同学都知道,apollo通过推拉结合的方式将服务端存储的应用配置文件缓存到本地是以properties的格式存储的,如下面所示:
demo+dev+logback.xml.properties
content=<?xml version/="1.0" encoding/="UTF-8"?>/n<configuration debug/="true">/n/t<property name/="encoding" value/="UTF-8"/>/n/n/t<appender name/="STDOUT" class/="ch.qos.logback.core.ConsoleAppender">/n/t/t<encoder class/="ch.qos.logback.classic.encoder.PatternLayoutEncoder">/n/t/t/t<pattern>%d{yyyy-MM-dd HH/:mm/:ss.SSS}|%X{requestId}|[%t] %-5level %logger{50} %line - %m%n</pattern>/n/t/t</encoder>/n/t</appender>/n/n/t<appender name/="FILE" class/="ch.qos.logback.core.rolling.RollingFileAppender">/n/t/t<file>logs/brm.log</file>/n/t/t<encoder class/="ch.qos.logback.classic.encoder.PatternLayoutEncoder">/n/t/t/t<pattern>%d{yyyy-MM-dd HH/:mm/:ss.SSS}|%X{requestId}|%X{requestSeq}|[%t] %-5level %logger{50} %line - %m%n</pattern>/n/t/t</encoder>/n/t/t<rollingPolicy class/="ch.qos.logback.core.rolling.SizeAndTimeBasedRollingPolicy">/n/t/t/t<fileNamePattern>logs/brm-%d{yyyy-MM-dd-HH}-%i.log</fileNamePattern>>/n/t/t/t</!--单个文件切割阈值,超过生成新log文件-->/n/t/t/t<maxFileSize>200MB</maxFileSize>/n/t/t/t</!--最大保留天数-->/n/t/t/t<maxHistory>336</maxHistory>/n/t/t</rollingPolicy>/n/t</appender>/n/n </!--log4jdbc -->/n <logger name/="jdbc.sqltiming" level/="INFO"/>/n <logger name/="jdbc.sqlonly" level/="OFF"/>/n <logger name/="jdbc.audit" level/="OFF"/>/n <logger name/="jdbc.resultset" level/="OFF"/>/n <logger name/="jdbc.resultsettable" level/="OFF"/>/n <logger name/="jdbc.connection" level/="OFF"/>/n /n/t<root level/="INFO">/n/t/t<appender-ref ref/="STDOUT"/>/n/t/t<appender-ref ref/="FILE"/>/n/t</root>/n</configuration>
而我们通常在配置logback的时候使用的是xml文件;
因此,我们要想办法让logback能够加载context的内存值信息。
阅读logback资料发现,JoranConfigurator支持我们以自定义的方式配置logback,
而springboot是通过LoggingSystem来加载管理日志系统的;如果我能在springboot启动的时候指定我自定义的日志加载类,问题便迎刃而解。
这里,我们在resources目录下新建META-INF文件夹,添加spring.factories,内容如下:
org.springframework.context.ApplicationContextInitializer = com.zhoupu.zplog.refresher.LoggerRefresher org.springframework.boot.env.EnvironmentPostProcessor = com.zhoupu.zplog.refresher.LoggerRefresher
这里我们定义一个LoggerRefresher,该类重写loadDefaults和loadConfiguration方法,通过JoranConfigurator加载logback配置,并在configureByApollo中添加一个apollo事件监听器,当发现logback.xml文件有变化时,重新执行configureByApollo方法刷新日志配置。
核心代码部分如下:
package com.zhoupu.zplog.refresher; import ch.qos.logback.classic.LoggerContext; import ch.qos.logback.classic.joran.JoranConfigurator; import ch.qos.logback.core.joran.spi.JoranException; import com.ctrip.framework.apollo.Config; import com.ctrip.framework.apollo.ConfigChangeListener; import com.ctrip.framework.apollo.ConfigService; import com.ctrip.framework.apollo.model.ConfigChangeEvent; import com.ctrip.framework.apollo.spring.config.PropertySourcesConstants; import org.slf4j.ILoggerFactory; import org.slf4j.Logger; import org.slf4j.LoggerFactory; import org.springframework.boot.SpringApplication; import org.springframework.boot.env.EnvironmentPostProcessor; import org.springframework.context.ApplicationContextInitializer; import org.springframework.context.ConfigurableApplicationContext; import org.springframework.core.Ordered; import org.springframework.core.env.ConfigurableEnvironment; import org.springframework.util.StringUtils; import javax.xml.parsers.DocumentBuilder; import javax.xml.parsers.DocumentBuilderFactory; import java.io.ByteArrayInputStream; import java.io.UnsupportedEncodingException; /** * * @author vigor * @date 2019/6/14 上午11:27 */ public class LoggerRefresher implements ApplicationContextInitializer<ConfigurableApplicationContext>, EnvironmentPostProcessor, Ordered { private static final Logger log = LoggerFactory.getLogger(LoggerRefresher.class); private boolean loadFlag = false; @Override public void initialize(ConfigurableApplicationContext context) { ConfigurableEnvironment environment = context.getEnvironment(); load(environment); } @Override public void postProcessEnvironment(ConfigurableEnvironment environment, SpringApplication application) { load(environment); } @Override public int getOrder() { return 1; } private void load(ConfigurableEnvironment environment) { if (!loadFlag) { environment.getPropertySources().forEach(ps -> { if (PropertySourcesConstants.APOLLO_BOOTSTRAP_PROPERTY_SOURCE_NAME.equals(ps.getName())) { configureByApollo(); loadFlag = true; } }); } } private void configureByApollo() { Config config = ConfigService.getConfig("logback.xml"); String content = config.getProperty("content", ""); if (StringUtils.isEmpty(content) || !validateXML(content)) { return; } config.addChangeListener(new ConfigChangeListener() { @Override public void onChange(ConfigChangeEvent changeEvent) { configureByApollo(); } @Override public boolean equals(Object obj) { if (this == obj) { return true; } if (this.getClass().equals(obj.getClass())) { return true; } return false; } @Override public int hashCode() { return 1; } }); ILoggerFactory loggerFactory = LoggerFactory.getILoggerFactory(); LoggerContext loggerContext = (LoggerContext) loggerFactory; loggerContext.reset(); JoranConfigurator configurator = new JoranConfigurator(); configurator.setContext(loggerContext); try { configurator.doConfigure(new ByteArrayInputStream(content.getBytes("utf-8"))); log.warn("*****************************logback configureByApollo success!********************************"); } catch (JoranException e) { e.printStackTrace(); } catch (UnsupportedEncodingException e) { e.printStackTrace(); } } private boolean validateXML(String xml){ boolean isValidated = true; try { DocumentBuilderFactory documentBuilderFactory = DocumentBuilderFactory.newInstance(); DocumentBuilder builder = documentBuilderFactory.newDocumentBuilder(); builder.parse(new ByteArrayInputStream(xml.getBytes("utf-8"))); } catch (Exception e) { log.error("apollo logback config error = {}", e); isValidated = false; } return isValidated; } }
至此已完成所有准备工作,运行demo程序,我的项目使用log4jdbc输出sql,这里我通过修改apollo配置管理后台jdbc日志配置,将sqltiming级别改为INFO:
<!--log4jdbc --> <logger name="jdbc.sqltiming" level="INFO"/> <logger name="jdbc.sqlonly" level="OFF"/> <logger name="jdbc.audit" level="OFF"/> <logger name="jdbc.resultset" level="OFF"/> <logger name="jdbc.resultsettable" level="OFF"/> <logger name="jdbc.connection" level="OFF"/>
发起一个后端请求,查看控制台日志输出,有了!
2019-11-08 10:11:27.794|1fe97e7dcfeb4fc2810d8a7a706fad2a||[http-nio-8062-exec-3] INFO jdbc.sqltiming 357 - SELECT id, row_state, created_at, updated_at, created_by, updated_by, business_id, contact_name, role, mobile, contact_type FROM t_business_contact WHERE row_state = 0 AND business_id = 1000006
惊不惊喜_,意不意外!
一个简单的日志配置热更新尝试,串联起了logback的自定义配置加载原理,apollo的配置中心使用方法和事件监听机制,以及springboot日志管理和自动装配等知识点,希望大家能从中有所收获!
